OpenBuilds Part Store

C-Beam® Linear Rail

$7.00

C-Beam® Linear Rail

$7.00
SKU:
05 - LP
Share

Product Description

C-Beam® Linear Rail

You now have access to utilize the power of beams in your builds!


  • C-Beam is a profile based on the popular V-Slot linear guide system. It incorporates a C shape profile which gives added strength and functionality.

  • Since C-Beam is a product of the V-Slot line all standard V-Slot parts and accessores are compatible! Of course, like V-Slot, every side of C-Beam can be used a linear guide.

  • C-Beam is available in multiple lengths and comes pre-tapped  with 4 holes ready to accept C-Beam end mounts. This allows you to quickly create C-Beam linear actuators.

  • You can add multiple plates for added precision and strength.

  • You can use any of the V-Slot gantry plates with C-Beam.

  • You can even 3D Print your own parts to produce customized creations.

  • C-Beam is extremely modular which allows for practically unlimited mounting possibilities and build configurations.



 dsc03854.jpg  dsc03855.jpg

C-Beam® Details

OpenBuilds C-Beam is made with 6063 T-5 Aluminum and it has a beautiful, shiny, super smooth, clear finish.  The finish is much shinier than standard profiles which allows for a smoother ride for the OpenBuilds V Wheels.

C-Beam Linear Rail is considered to be a 40mm x 80mm profile which is compatible with all V-Slot Parts and Accessories.

C-Beam Weights

250mm 1 lb. 2 oz.
500mm 2 lbs. 4 oz.
1000mm 4 lbs. 4 oz.

Be sure to download the Example C-Beam builds from OpenBuilds to use C-Beam in your own Builds!






We think you will agree C-Beams are awesome and we look forward to all of the wonderful builds you create with them!

Download Model

C-Beam Actuator example builds for inspration and use in your own builds!

 Download
